Morsø S10-70

Morsø S10-70

Output
3-7 kw
Height 735 mm
Width 456 mm
Depth 409 mm
Weight 102 kg
Log Lenght
30 cm











FEATURES

  • Convection system
  • Air wash system
  • Pre-heated combustion air
  • Pre-heated secondary air
  • Tertiary air supply
  • Ash can
  • Optional air kit available

FUEL

  • Wood and briquettes

COLOURS

  • Dark grey

APPROVALS

  • EN 1324
  • Norwegian Approval
  • DIN+/AT
  • DEFRA Approved for use in smoke control areas

DIAGRAMS, MANUALS AND DOWNLOADS



Technical details

Rated output (kw) 5
Log length (cm) 30
Flue outlet, internal ø (mm) 134
Minimum internal flue ø (mm) 125
Weight (Kg) 102
Efficiency Net / Gross (%) 81.3/74
Height (mm) 735
Width (mm) 456
Depth (mm) 409

Clearances to combustibles

Top (mm) 600
Sides (mm) 400
Rear (mm)
 200
Soft furniture (mm) 700
Above the floor (mm) 300*
*Combustible Floors

If the stove is installed over combustible flooring, a 12mm thick non-combustible floor protection must cover the floor under the stove and extend at least 300mm in front and 150mm either side of the stove.

The minimum clearance from the non-combustible floor protection to the under side of the stove is 300mm
